E-Nose Sniffs Out Coffee Varieties Nearly Perfectly

This article is part of our exclusive IEEE Journal Watch series in partnership with IEEE Xplore.

Some truly passionate java junkies may be adept at distinguishing between various coffee flavors, but a new e-nose may give these folks a run for their money. The new sensing system, which can distinguish coffee aromas consistently with 98 percent accuracy, is described in a study published last month in IEEE Transactions on AgriFood Electronics.

E-noses are devices that assess gasses to classify the nature of the substance at hand. They are growing in popularity, thanks to their ability to facilitate quality assurance of products (e.g. whiskey), provide real-time health assessments (e.g. an individual’s glucose levels), and to support sustainable agriculture (e.g. identify when a crop is ready for harvesting).

“The broader goal is to contribute to the preservation and understanding of aromas in the face of environmental changes.”
—Chung-Hone Lee, National Kaohsiung University of Science and Technology, Taiwan

Chung-Hong Lee, a professor at the Department of Electrical Engineering at the National Kaohsiung University of Science and Technology, in Taiwan, is a passionate coffee drinker and was interested in applying e-nose technology in the context of one of his favorite beverages.

He notes that coffee varieties rely on an array of factors, including growing area, climate, post-harvest processing (such as dry and wet methods), roasting treatment, and the genetic makeup of beans themselves. But, importantly, climate change is altering the local environments that influence bean flavor and aroma.

“Beyond [my] personal enjoyment of coffee, the broader goal is to contribute to the preservation and understanding of aromas in the face of environmental changes, ensuring consistency in quality and flavor profiles across different crop years,” explains Lee.

To create their e-nose, Lee’s his team used an array of eight commercial metal semiconductor oxide sensors that are sensitive to specific gases. These sensors detect which molecules are present, data that is then sent to an AI algorithm for processing. The researchers then trained and tested several different AI systems that could distinguish among 16 different coffee bean varieties from around the world.

All of the AI algorithms performed very well, achieving an accuracy ranging from 81 to 98 percent, depending on the type of coffee. The best performing algorithm—one called a convolutional neural network (CNN) algorithm – nearly always had an accuracy exceeding 90 percent and reached an accuracy as high as 98 percent for several coffee varieties.

“Thus, the journey from drinking coffee to unraveling its aromatic secrets becomes a natural fusion of sensory delight and cutting-edge technology,” says Lee.

However, the value in this work goes beyond simply identifying the cup of coffee at hand. Lee’s team is using these data from their e-nose to build a comprehensive digital library of coffee aromas, capturing the diverse and complex profiles from various coffee-producing regions globally. Notably, this digital library of coffee flavors could create a benchmark for original flavors, and how they are affected over time as climate change affects coffee bean agriculture. Or, for example, if some deceitful seller tries to market one bean variety as another, this tech could help ensure that bean fiends get the right cup of coffee they ordered.

Lee says his team is interested in commercializing their e-nose, and they are open to collaboration with enterprises or startups interested in leveraging this technology. As well, he sees the possibility of creating not just e-noses for coffee, but also an electronic tongue for detecting coffee taste, an electronic eye for filtering the best ripe coffee—even a tactile system for assessing the moisture content of coffee beans. “This next step is crucial for establishing and progressing toward addressing issues in coffee-growing areas and benefiting farmers,” Lee emphasizes.
